HTTP API Reference

A complete reference for RAGFlow's RESTful API. Before proceeding, please ensure you have your RAGFlow API key ready for authentication.

DATASET MANAGEMENT​

Create dataset​

POST /api/v1/datasets

Creates a dataset.

Request​

  • Method: POST
  • URL: /api/v1/datasets
  • Headers:
    • 'content-Type: application/json'
    • 'Authorization: Bearer <YOUR_API_KEY>'
  • Body:
    • "name": string
    • "avatar": string
    • "description": string
    • "language": string
    • "embedding_model": string
    • "permission": string
    • "chunk_method": string
    • "parser_config": object
Request example​
curl --request POST \
     --url http://{address}/api/v1/datasets \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data '{
      "name": "test_1"
      }'
Request parameters​

  • "name": (Body parameter), string, Required
    The unique name of the dataset to create. It must adhere to the following requirements:

    • Permitted characters include:
      • English letters (a-z, A-Z)
      • Digits (0-9)
      • "_" (underscore)
    • Must begin with an English letter or underscore.
    • Maximum 65,535 characters.
    • Case-insensitive.

  • "avatar": (Body parameter), string
    Base64 encoding of the avatar.

  • "description": (Body parameter), string
    A brief description of the dataset to create.

  • "language": (Body parameter), string
    The language setting of the dataset to create. Available options:

    • "English" (default)
    • "Chinese"

  • "embedding_model": (Body parameter), string
    The name of the embedding model to use. For example: "BAAI/bge-zh-v1.5"

  • "permission": (Body parameter), string
    Specifies who can access the dataset to create. Available options:

    • "me": (Default) Only you can manage the dataset.
    • "team": All team members can manage the dataset.

  • "chunk_method": (Body parameter), enum<string>
    The chunking method of the dataset to create. Available options:

    • "naive": General (default)
    • "manual": Manual
    • "qa": Q&A
    • "table": Table
    • "paper": Paper
    • "book": Book
    • "laws": Laws
    • "presentation": Presentation
    • "picture": Picture
    • "one": One
    • "knowledge_graph": Knowledge Graph
      Ensure your LLM is properly configured on the Settings page before selecting this. Please also note that Knowledge Graph consumes a large number of Tokens!
    • "email": Email

  • "parser_config": (Body parameter), object
    The configuration settings for the dataset parser. The attributes in this JSON object vary with the selected "chunk_method":

    • If "chunk_method" is "naive", the "parser_config" object contains the following attributes:
      • "chunk_token_count": Defaults to 128.
      • "layout_recognize": Defaults to true.
      • "html4excel": Indicates whether to convert Excel documents into HTML format. Defaults to false.
      • "delimiter": Defaults to "\n!?。；！？".
      • "task_page_size": Defaults to 12. For PDF only.
      • "raptor": Raptor-specific settings. Defaults to: {"use_raptor": false}.
    • If "chunk_method" is "qa", "manuel", "paper", "book", "laws", or "presentation", the "parser_config" object contains the following attribute:
      • "raptor": Raptor-specific settings. Defaults to: {"use_raptor": false}.
    • If "chunk_method" is "table", "picture", "one", or "email", "parser_config" is an empty JSON object.
    • If "chunk_method" is "knowledge_graph", the "parser_config" object contains the following attributes:
      • "chunk_token_count": Defaults to 128.
      • "delimiter": Defaults to "\n!?。；！？".
      • "entity_types": Defaults to ["organization","person","location","event","time"]

Response​

Success:

{
    "code": 0,
    "data": {
        "avatar": null,
        "chunk_count": 0,
        "chunk_method": "naive",
        "create_date": "Thu, 24 Oct 2024 09:14:07 GMT",
        "create_time": 1729761247434,
        "created_by": "69736c5e723611efb51b0242ac120007",
        "description": null,
        "document_count": 0,
        "embedding_model": "BAAI/bge-large-zh-v1.5",
        "id": "527fa74891e811ef9c650242ac120006",
        "language": "English",
        "name": "test_1",
        "parser_config": {
            "chunk_token_num": 128,
            "delimiter": "\\n!?;。；！？",
            "html4excel": false,
            "layout_recognize": true,
            "raptor": {
                "user_raptor": false
            }
        },
        "permission": "me",
        "similarity_threshold": 0.2,
        "status": "1",
        "tenant_id": "69736c5e723611efb51b0242ac120007",
        "token_num": 0,
        "update_date": "Thu, 24 Oct 2024 09:14:07 GMT",
        "update_time": 1729761247434,
        "vector_similarity_weight": 0.3
    }
}

Failure:

{
    "code": 102,
    "message": "Duplicated knowledgebase name in creating dataset."
}

Delete datasets​

DELETE /api/v1/datasets

Deletes datasets by ID.

Request​

  • Method: DELETE
  • URL: /api/v1/datasets
  • Headers:
    • 'content-Type: application/json'
    • 'Authorization: Bearer <YOUR_API_KEY>'
    • Body:
      • "ids": list[string]
Request example​
curl --request DELETE \
     --url http://{address}/api/v1/datasets \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data '{
     "ids": ["test_1", "test_2"]
     }'
Request parameters​
  • "ids": (Body parameter), list[string]
    The IDs of the datasets to delete. If it is not specified, all datasets will be deleted.

Response​

Success:

{
    "code": 0
}

Failure:

{
    "code": 102,
    "message": "You don't own the dataset."
}

Update dataset​

PUT /api/v1/datasets/{dataset_id}

Updates configurations for a specified dataset.

Request​

  • Method: PUT
  • URL: /api/v1/datasets/{dataset_id}
  • Headers:
    • 'content-Type: application/json'
    • 'Authorization: Bearer <YOUR_API_KEY>'
  • Body:
    • "name": string
    • "embedding_model": string
    • "chunk_method": enum<string>
Request example​
curl --request PUT \
     --url http://{address}/api/v1/datasets/{dataset_id} \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data '
     {
          "name": "updated_dataset"
     }'
Request parameters​
  • dataset_id: (Path parameter)
    The ID of the dataset to update.
  • "name": (Body parameter), string
    The revised name of the dataset.
  • "embedding_model": (Body parameter), string
    The updated embedding model name.
    • Ensure that "chunk_count" is 0 before updating "embedding_model".
  • "chunk_method": (Body parameter), enum<string>
    The chunking method for the dataset. Available options:
    • "naive": General
    • "manual: Manual
    • "qa": Q&A
    • "table": Table
    • "paper": Paper
    • "book": Book
    • "laws": Laws
    • "presentation": Presentation
    • "picture": Picture
    • "one":One
    • "email": Email
    • "knowledge_graph": Knowledge Graph
      Ensure your LLM is properly configured on the Settings page before selecting this. Please also note that Knowledge Graph consumes a large number of Tokens!

Response​

Success:

{
    "code": 0
}

Failure:

{
    "code": 102,
    "message": "Can't change tenant_id."
}

List datasets​

GET /api/v1/datasets?page={page}&page_size={page_size}&orderby={orderby}&desc={desc}&name={dataset_name}&id={dataset_id}

Lists datasets.

Request​

  • Method: GET
  • URL: /api/v1/datasets?page={page}&page_size={page_size}&orderby={orderby}&desc={desc}&name={dataset_name}&id={dataset_id}
  • Headers:
    • 'Authorization: Bearer <YOUR_API_KEY>'
Request example​
curl --request GET \
     --url http://{address}/api/v1/datasets?page={page}&page_size={page_size}&orderby={orderby}&desc={desc}&name={dataset_name}&id={dataset_id} \
     --header 'Authorization: Bearer <YOUR_API_KEY>'
Request parameters​
  • page: (Filter parameter)
    Specifies the page on which the datasets will be displayed. Defaults to 1.
  • page_size: (Filter parameter)
    The number of datasets on each page. Defaults to 30.
  • orderby: (Filter parameter)
    The field by which datasets should be sorted. Available options:
    • create_time (default)
    • update_time
  • desc: (Filter parameter)
    Indicates whether the retrieved datasets should be sorted in descending order. Defaults to true.
  • name: (Filter parameter)
    The name of the dataset to retrieve.
  • id: (Filter parameter)
    The ID of the dataset to retrieve.

Response​

Success:

{
    "code": 0,
    "data": [
        {
            "avatar": "",
            "chunk_count": 59,
            "create_date": "Sat, 14 Sep 2024 01:12:37 GMT",
            "create_time": 1726276357324,
            "created_by": "69736c5e723611efb51b0242ac120007",
            "description": null,
            "document_count": 1,
            "embedding_model": "BAAI/bge-large-zh-v1.5",
            "id": "6e211ee0723611efa10a0242ac120007",
            "language": "English",
            "name": "mysql",
            "chunk_method": "knowledge_graph",
            "parser_config": {
                "chunk_token_num": 8192,
                "delimiter": "\\n!?;。；！？",
                "entity_types": [
                    "organization",
                    "person",
                    "location",
                    "event",
                    "time"
                ]
            },
            "permission": "me",
            "similarity_threshold": 0.2,
            "status": "1",
            "tenant_id": "69736c5e723611efb51b0242ac120007",
            "token_num": 12744,
            "update_date": "Thu, 10 Oct 2024 04:07:23 GMT",
            "update_time": 1728533243536,
            "vector_similarity_weight": 0.3
        }
    ]
}

Failure:

{
    "code": 102,
    "message": "The dataset doesn't exist"
}

FILE MANAGEMENT WITHIN DATASET​

Upload documents​

POST /api/v1/datasets/{dataset_id}/documents

Uploads documents to a specified dataset.

Request​

  • Method: POST
  • URL: /api/v1/datasets/{dataset_id}/documents
  • Headers:
    • 'Content-Type: multipart/form-data'
    • 'Authorization: Bearer <YOUR_API_KEY>'
  • Form:
    • 'file=@{FILE_PATH}'
Request example​
curl --request POST \
     --url http://{address}/api/v1/datasets/{dataset_id}/documents \
     --header 'Content-Type: multipart/form-data' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --form 'file=@./test1.txt' \
     --form 'file=@./test2.pdf'
Request parameters​
  • dataset_id: (Path parameter)
    The ID of the dataset to which the documents will be uploaded.
  • 'file': (Body parameter)
    A document to upload.

Response​

Success:

{
    "code": 0,
    "data": [
        {
            "chunk_method": "naive",
            "created_by": "69736c5e723611efb51b0242ac120007",
            "dataset_id": "527fa74891e811ef9c650242ac120006",
            "id": "b330ec2e91ec11efbc510242ac120004",
            "location": "1.txt",
            "name": "1.txt",
            "parser_config": {
                "chunk_token_num": 128,
                "delimiter": "\\n!?;。；！？",
                "html4excel": false,
                "layout_recognize": true,
                "raptor": {
                    "user_raptor": false
                }
            },
            "run": "UNSTART",
            "size": 17966,
            "thumbnail": "",
            "type": "doc"
        }
    ]
}

Failure:

{
    "code": 101,
    "message": "No file part!"
}

Update document​

PUT /api/v1/datasets/{dataset_id}/documents/{document_id}

Updates configurations for a specified document.

Request​

  • Method: PUT
  • URL: /api/v1/datasets/{dataset_id}/documents/{document_id}
  • Headers:
    • 'content-Type: application/json'
    • 'Authorization: Bearer <YOUR_API_KEY>'
  • Body:
    • "name":string
    • "chunk_method":string
    • "parser_config":object
Request example​
curl --request PUT \
     --url http://{address}/api/v1/datasets/{dataset_id}/info/{document_id} \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --header 'Content-Type: application/json' \
     --data '
     {
          "name": "manual.txt",
          "chunk_method": "manual",
          "parser_config": {"chunk_token_count": 128}
     }'

Request parameters​
  • dataset_id: (Path parameter)
    The ID of the associated dataset.
  • document_id: (Path parameter)
    The ID of the document to update.
  • "name": (Body parameter), string
  • "chunk_method": (Body parameter), string
    The parsing method to apply to the document:
    • "naive": General
    • "manual: Manual
    • "qa": Q&A
    • "table": Table
    • "paper": Paper
    • "book": Book
    • "laws": Laws
    • "presentation": Presentation
    • "picture": Picture
    • "one": One
    • "knowledge_graph": Knowledge Graph
      Ensure your LLM is properly configured on the Settings page before selecting this. Please also note that Knowledge Graph consumes a large number of Tokens!
    • "email": Email
  • "parser_config": (Body parameter), object
    The configuration settings for the dataset parser. The attributes in this JSON object vary with the selected "chunk_method":
    • If "chunk_method" is "naive", the "parser_config" object contains the following attributes:
      • "chunk_token_count": Defaults to 128.
      • "layout_recognize": Defaults to true.
      • "html4excel": Indicates whether to convert Excel documents into HTML format. Defaults to false.
      • "delimiter": Defaults to "\n!?。；！？".
      • "task_page_size": Defaults to 12. For PDF only.
      • "raptor": Raptor-specific settings. Defaults to: {"use_raptor": false}.
    • If "chunk_method" is "qa", "manuel", "paper", "book", "laws", or "presentation", the "parser_config" object contains the following attribute:
      • "raptor": Raptor-specific settings. Defaults to: {"use_raptor": false}.
    • If "chunk_method" is "table", "picture", "one", or "email", "parser_config" is an empty JSON object.
    • If "chunk_method" is "knowledge_graph", the "parser_config" object contains the following attributes:
      • "chunk_token_count": Defaults to 128.
      • "delimiter": Defaults to "\n!?。；！？".
      • "entity_types": Defaults to ["organization","person","location","event","time"]

Response​

Success:

{
    "code": 0
}

Failure:

{
    "code": 102,
    "message": "The dataset does not have the document."
}

Download document​

GET /api/v1/datasets/{dataset_id}/documents/{document_id}

Downloads a document from a specified dataset.

Request​

  • Method: GET
  • URL: /api/v1/datasets/{dataset_id}/documents/{document_id}
  • Headers:
    • 'Authorization: Bearer <YOUR_API_KEY>'
  • Output:
    • '{PATH_TO_THE_FILE}'
Request example​
curl --request GET \
     --url http://{address}/api/v1/datasets/{dataset_id}/documents/{document_id} \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --output ./ragflow.txt
Request parameters​
  • dataset_id: (Path parameter)
    The associated dataset ID.
  • documents_id: (Path parameter)
    The ID of the document to download.

Response​

Success:

This is a test to verify the file download feature.

Failure:

{
    "code": 102,
    "message": "You do not own the dataset 7898da028a0511efbf750242ac1220005."
}

List documents​

GET /api/v1/datasets/{dataset_id}/documents?page={page}&page_size={page_size}&orderby={orderby}&desc={desc}&keywords={keywords}&id={document_id}&name={document_name}

Lists documents in a specified dataset.

Request​

  • Method: GET
  • URL: /api/v1/datasets/{dataset_id}/documents?page={page}&page_size={page_size}&orderby={orderby}&desc={desc}&keywords={keywords}&id={document_id}&name={document_name}
  • Headers:
    • 'content-Type: application/json'
    • 'Authorization: Bearer <YOUR_API_KEY>'
Request example​
curl --request GET \
     --url http://{address}/api/v1/datasets/{dataset_id}/documents?page={page}&page_size={page_size}&orderby={orderby}&desc={desc}&keywords={keywords}&id={document_id}&name={document_name} \
     --header 'Authorization: Bearer <YOUR_API_KEY>'
Request parameters​
  • dataset_id: (Path parameter)
    The associated dataset ID.
  • keywords: (Filter parameter), string
    The keywords used to match document titles.
  • page: (Filter parameter), integer Specifies the page on which the documents will be displayed. Defaults to 1.
  • page_size: (Filter parameter), integer
    The maximum number of documents on each page. Defaults to 30.
  • orderby: (Filter parameter), string
    The field by which documents should be sorted. Available options:
    • create_time (default)
    • update_time
  • desc: (Filter parameter), boolean
    Indicates whether the retrieved documents should be sorted in descending order. Defaults to true.
  • id: (Filter parameter), string
    The ID of the document to retrieve.

Response​

Success:

{
    "code": 0,
    "data": {
        "docs": [
            {
                "chunk_count": 0,
                "create_date": "Mon, 14 Oct 2024 09:11:01 GMT",
                "create_time": 1728897061948,
                "created_by": "69736c5e723611efb51b0242ac120007",
                "id": "3bcfbf8a8a0c11ef8aba0242ac120006",
                "knowledgebase_id": "7898da028a0511efbf750242ac120005",
                "location": "Test_2.txt",
                "name": "Test_2.txt",
                "parser_config": {
                    "chunk_token_count": 128,
                    "delimiter": "\n!?。；！？",
                    "layout_recognize": true,
                    "task_page_size": 12
                },
                "chunk_method": "naive",
                "process_begin_at": null,
                "process_duation": 0.0,
                "progress": 0.0,
                "progress_msg": "",
                "run": "0",
                "size": 7,
                "source_type": "local",
                "status": "1",
                "thumbnail": null,
                "token_count": 0,
                "type": "doc",
                "update_date": "Mon, 14 Oct 2024 09:11:01 GMT",
                "update_time": 1728897061948
            }
        ],
        "total": 1
    }
}

Failure:

{
    "code": 102,
    "message": "You don't own the dataset 7898da028a0511efbf750242ac1220005. "
}

Delete documents​

DELETE /api/v1/datasets/{dataset_id}/documents

Deletes documents by ID.

Request​

  • Method: DELETE
  • URL: /api/v1/datasets/{dataset_id}/documents
  • Headers:
    • 'Content-Type: application/json'
    • 'Authorization: Bearer <YOUR_API_KEY>'
  • Body:
    • "ids": list[string]
Request example​
curl --request DELETE \
     --url http://{address}/api/v1/datasets/{dataset_id}/documents \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data '
     {
          "ids": ["id_1","id_2"]
     }'
Request parameters​
  • dataset_id: (Path parameter)
    The associated dataset ID.
  • "ids": (Body parameter), list[string]
    The IDs of the documents to delete. If it is not specified, all documents in the specified dataset will be deleted.

Response​

Success:

{
    "code": 0
}.

Failure:

{
    "code": 102,
    "message": "You do not own the dataset 7898da028a0511efbf750242ac1220005."
}

Parse documents​

POST /api/v1/datasets/{dataset_id}/chunks

Parses documents in a specified dataset.

Request​

  • Method: POST
  • URL: /api/v1/datasets/{dataset_id}/chunks
  • Headers:
    • 'content-Type: application/json'
    • 'Authorization: Bearer <YOUR_API_KEY>'
  • Body:
    • "document_ids": list[string]
Request example​
curl --request POST \
     --url http://{address}/api/v1/datasets/{dataset_id}/chunks \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data '
     {
          "document_ids": ["97a5f1c2759811efaa500242ac120004","97ad64b6759811ef9fc30242ac120004"]
     }'
Request parameters​
  • dataset_id: (Path parameter)
    The dataset ID.
  • "document_ids": (Body parameter), list[string], Required
    The IDs of the documents to parse.

Response​

Success:

{
    "code": 0
}

Failure:

{
    "code": 102,
    "message": "`document_ids` is required"
}

Stop parsing documents​

DELETE /api/v1/datasets/{dataset_id}/chunks

Stops parsing specified documents.

Request​

  • Method: DELETE
  • URL: /api/v1/datasets/{dataset_id}/chunks
  • Headers:
    • 'content-Type: application/json'
    • 'Authorization: Bearer <YOUR_API_KEY>'
  • Body:
    • "document_ids": list[string]
Request example​
curl --request DELETE \
     --url http://{address}/api/v1/datasets/{dataset_id}/chunks \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data '
     {
          "document_ids": ["97a5f1c2759811efaa500242ac120004","97ad64b6759811ef9fc30242ac120004"]
     }'
Request parameters​
  • dataset_id: (Path parameter)
    The associated dataset ID.
  • "document_ids": (Body parameter), list[string], Required
    The IDs of the documents for which the parsing should be stopped.

Response​

Success:

{
    "code": 0
}

Failure:

{
    "code": 102,
    "message": "`document_ids` is required"
}

Add chunk​

POST /api/v1/datasets/{dataset_id}/documents/{document_id}/chunks

Adds a chunk to a specified document in a specified dataset.

Request​

  • Method: POST
  • URL: /api/v1/datasets/{dataset_id}/documents/{document_id}/chunks
  • Headers:
    • 'content-Type: application/json'
    • 'Authorization: Bearer <YOUR_API_KEY>'
  • Body:
    • "content": string
    • "important_keywords": list[string]
Request example​
curl --request POST \
     --url http://{address}/api/v1/datasets/{dataset_id}/documents/{document_id}/chunks \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data '
     {
          "content": "<CHUNK_CONTENT_HERE>"
     }'
Request parameters​
  • dataset_id: (Path parameter)
    The associated dataset ID.
  • document_ids: (Path parameter)
    The associated document ID.
  • "content": (Body parameter), string, Required
    The text content of the chunk.
  • "important_keywords(Body parameter), list[string]
    The key terms or phrases to tag with the chunk.

Response​

Success:

{
    "code": 0,
    "data": {
        "chunk": {
            "content": "ragflow content",
            "create_time": "2024-10-16 08:05:04",
            "create_timestamp": 1729065904.581025,
            "dataset_id": [
                "c7ee74067a2c11efb21c0242ac120006"
            ],
            "document_id": "5c5999ec7be811ef9cab0242ac120005",
            "id": "d78435d142bd5cf6704da62c778795c5",
            "important_keywords": []
        }
    }
}

Failure:

{
    "code": 102,
    "message": "`content` is required"
}

List chunks​

GET /api/v1/datasets/{dataset_id}/documents/{document_id}/chunks?keywords={keywords}&page={page}&page_size={page_size}&id={id}

Lists chunks in a specified document.

Request​

  • Method: GET
  • URL: /api/v1/datasets/{dataset_id}/documents/{document_id}/chunks?keywords={keywords}&page={page}&page_size={page_size}&id={chunk_id}
  • Headers:
    • 'Authorization: Bearer <YOUR_API_KEY>'
Request example​
curl --request GET \
     --url http://{address}/api/v1/datasets/{dataset_id}/documents/{document_id}/chunks?keywords={keywords}&page={page}&page_size={page_size}&id={chunk_id} \
     --header 'Authorization: Bearer <YOUR_API_KEY>'
Request parameters​
  • dataset_id: (Path parameter)
    The associated dataset ID.
  • document_ids: (Path parameter)
    The associated document ID.
  • keywords(Filter parameter), string
    The keywords used to match chunk content.
  • page(Filter parameter), integer
    Specifies the page on which the chunks will be displayed. Defaults to 1.
  • page_size(Filter parameter), integer
    The maximum number of chunks on each page. Defaults to 1024.
  • id(Filter parameter), string
    The ID of the chunk to retrieve.

Response​

Success:

{
    "code": 0,
    "data": {
        "chunks": [
            {
                "available_int": 1,
                "content": "This is a test content.",
                "docnm_kwd": "1.txt",
                "document_id": "b330ec2e91ec11efbc510242ac120004",
                "id": "b48c170e90f70af998485c1065490726",
                "image_id": "",
                "important_keywords": "",
                "positions": [
                    ""
                ]
            }
        ],
        "doc": {
            "chunk_count": 1,
            "chunk_method": "naive",
            "create_date": "Thu, 24 Oct 2024 09:45:27 GMT",
            "create_time": 1729763127646,
            "created_by": "69736c5e723611efb51b0242ac120007",
            "dataset_id": "527fa74891e811ef9c650242ac120006",
            "id": "b330ec2e91ec11efbc510242ac120004",
            "location": "1.txt",
            "name": "1.txt",
            "parser_config": {
                "chunk_token_num": 128,
                "delimiter": "\\n!?;。；！？",
                "html4excel": false,
                "layout_recognize": true,
                "raptor": {
                    "user_raptor": false
                }
            },
            "process_begin_at": "Thu, 24 Oct 2024 09:56:44 GMT",
            "process_duation": 0.54213,
            "progress": 0.0,
            "progress_msg": "Task dispatched...",
            "run": "2",
            "size": 17966,
            "source_type": "local",
            "status": "1",
            "thumbnail": "",
            "token_count": 8,
            "type": "doc",
            "update_date": "Thu, 24 Oct 2024 11:03:15 GMT",
            "update_time": 1729767795721
        },
        "total": 1
    }
}

Failure:

{
    "code": 102,
    "message": "You don't own the document 5c5999ec7be811ef9cab0242ac12000e5."
}

Delete chunks​

DELETE /api/v1/datasets/{dataset_id}/documents/{document_id}/chunks

Deletes chunks by ID.

Request​

  • Method: DELETE
  • URL: /api/v1/datasets/{dataset_id}/documents/{document_id}/chunks
  • Headers:
    • 'content-Type: application/json'
    • 'Authorization: Bearer <YOUR_API_KEY>'
  • Body:
    • "chunk_ids": list[string]
Request example​
curl --request DELETE \
     --url http://{address}/api/v1/datasets/{dataset_id}/documents/{document_id}/chunks \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data '
     {
          "chunk_ids": ["test_1", "test_2"]
     }'
Request parameters​
  • dataset_id: (Path parameter)
    The associated dataset ID.
  • document_ids: (Path parameter)
    The associated document ID.
  • "chunk_ids": (Body parameter), list[string]
    The IDs of the chunks to delete. If it is not specified, all chunks of the specified document will be deleted.

Response​

Success:

{
    "code": 0
}

Failure:

{
    "code": 102,
    "message": "`chunk_ids` is required"
}

Update chunk​

PUT /api/v1/datasets/{dataset_id}/documents/{document_id}/chunks/{chunk_id}

Updates content or configurations for a specified chunk.

Request​

  • Method: PUT
  • URL: /api/v1/datasets/{dataset_id}/documents/{document_id}/chunks/{chunk_id}
  • Headers:
    • 'content-Type: application/json'
    • 'Authorization: Bearer <YOUR_API_KEY>'
  • Body:
    • "content": string
    • "important_keywords": list[string]
    • "available": boolean
Request example​
curl --request PUT \
     --url http://{address}/api/v1/datasets/{dataset_id}/documents/{document_id}/chunks/{chunk_id} \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data '
     {
          "content": "ragflow123",
          "important_keywords": []
     }'
Request parameters​
  • dataset_id: (Path parameter)
    The associated dataset ID.
  • document_ids: (Path parameter)
    The associated document ID.
  • chunk_id: (Path parameter)
    The ID of the chunk to update.
  • "content": (Body parameter), string
    The text content of the chunk.
  • "important_keywords": (Body parameter), list[string]
    A list of key terms or phrases to tag with the chunk.
  • "available": (Body parameter) boolean
    The chunk's availability status in the dataset. Value options:
    • true: Available (default)
    • false: Unavailable

Response​

Success:

{
    "code": 0
}

Failure:

{
    "code": 102,
    "message": "Can't find this chunk 29a2d9987e16ba331fb4d7d30d99b71d2"
}

Retrieve chunks​

POST /api/v1/retrieval

Retrieves chunks from specified datasets.

Request​

  • Method: POST
  • URL: /api/v1/retrieval
  • Headers:
    • 'content-Type: application/json'
    • 'Authorization: Bearer <YOUR_API_KEY>'
  • Body:
    • "question": string
    • "dataset_ids": list[string]
    • "document_ids": list[string]
    • "page": integer
    • "page_size": integer
    • "similarity_threshold": float
    • "vector_similarity_weight": float
    • "top_k": integer
    • "rerank_id": string
    • "keyword": boolean
    • "highlight": boolean
Request example​
curl --request POST \
     --url http://{address}/api/v1/retrieval \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data '
     {
          "question": "What is advantage of ragflow?",
          "dataset_ids": ["b2a62730759d11ef987d0242ac120004"],
          "document_ids": ["77df9ef4759a11ef8bdd0242ac120004"]
     }'
Request parameter​
  • "question": (Body parameter), string, Required
    The user query or query keywords.
  • "dataset_ids": (Body parameter) list[string]
    The IDs of the datasets to search. If you do not set this argument, ensure that you set "document_ids".
  • "document_ids": (Body parameter), list[string]
    The IDs of the documents to search. Ensure that all selected documents use the same embedding model. Otherwise, an error will occur. If you do not set this argument, ensure that you set "dataset_ids".
  • "page": (Body parameter), integer
    Specifies the page on which the chunks will be displayed. Defaults to 1.
  • "page_size": (Body parameter)
    The maximum number of chunks on each page. Defaults to 30.
  • "similarity_threshold": (Body parameter)
    The minimum similarity score. Defaults to 0.2.
  • "vector_similarity_weight": (Body parameter), float
    The weight of vector cosine similarity. Defaults to 0.3. If x represents the weight of vector cosine similarity, then (1 - x) is the term similarity weight.
  • "top_k": (Body parameter), integer
    The number of chunks engaged in vector cosine computaton. Defaults to 1024.
  • "rerank_id": (Body parameter), integer
    The ID of the rerank model.
  • "keyword": (Body parameter), boolean
    Indicates whether to enable keyword-based matching:
    • true: Enable keyword-based matching.
    • false: Disable keyword-based matching (default).
  • "highlight": (Body parameter), boolean
    Specifies whether to enable highlighting of matched terms in the results:
    • true: Enable highlighting of matched terms.
    • false: Disable highlighting of matched terms (default).

Response​

Success:

{
    "code": 0,
    "data": {
        "chunks": [
            {
                "content": "ragflow content",
                "content_ltks": "ragflow content",
                "document_id": "5c5999ec7be811ef9cab0242ac120005",
                "document_keyword": "1.txt",
                "highlight": "<em>ragflow</em> content",
                "id": "d78435d142bd5cf6704da62c778795c5",
                "image_id": "",
                "important_keywords": [
                    ""
                ],
                "kb_id": "c7ee74067a2c11efb21c0242ac120006",
                "positions": [
                    ""
                ],
                "similarity": 0.9669436601210759,
                "term_similarity": 1.0,
                "vector_similarity": 0.8898122004035864
            }
        ],
        "doc_aggs": [
            {
                "count": 1,
                "doc_id": "5c5999ec7be811ef9cab0242ac120005",
                "doc_name": "1.txt"
            }
        ],
        "total": 1
    }
}

Failure:

{
    "code": 102,
    "message": "`datasets` is required."
}

CHAT ASSISTANT MANAGEMENT​

Create chat assistant​

POST /api/v1/chats

Creates a chat assistant.

Request​

  • Method: POST
  • URL: /api/v1/chats
  • Headers:
    • 'content-Type: application/json'
    • 'Authorization: Bearer <YOUR_API_KEY>'
  • Body:
    • "name": string
    • "avatar": string
    • "dataset_ids": list[string]
    • "llm": object
    • "prompt": object
Request example​
curl --request POST \
     --url http://{address}/api/v1/chats \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data '{
    "dataset_ids": ["0b2cbc8c877f11ef89070242ac120005"],
    "name":"new_chat_1"
}'
Request parameters​
  • "name": (Body parameter), string, Required
    The name of the chat assistant.
  • "avatar": (Body parameter), string
    Base64 encoding of the avatar.
  • "dataset_ids": (Body parameter), list[string]
    The IDs of the associated datasets.
  • "llm": (Body parameter), object
    The LLM settings for the chat assistant to create. If it is not explicitly set, a JSON object with the following values will be generated as the default. An llm JSON object contains the following attributes:
    • "model_name", string
      The chat model name. If not set, the user's default chat model will be used.
    • "temperature": float
      Controls the randomness of the model's predictions. A lower temperature results in more conservative responses, while a higher temperature yields more creative and diverse responses. Defaults to 0.1.
    • "top_p": float
      Also known as “nucleus sampling”, this parameter sets a threshold to select a smaller set of words to sample from. It focuses on the most likely words, cutting off the less probable ones. Defaults to 0.3
    • "presence_penalty": float
      This discourages the model from repeating the same information by penalizing words that have already appeared in the conversation. Defaults to 0.2.
    • "frequency penalty": float
      Similar to the presence penalty, this reduces the model’s tendency to repeat the same words frequently. Defaults to 0.7.
    • "max_token": integer
      The maximum length of the model's output, measured in the number of tokens (words or pieces of words). Defaults to 512. If disabled, you lift the maximum token limit, allowing the model to determine the number of tokens in its responses.
  • "prompt": (Body parameter), object
    Instructions for the LLM to follow. If it is not explicitly set, a JSON object with the following values will be generated as the default. A prompt JSON object contains the following attributes:
    • "similarity_threshold": float RAGFlow employs either a combination of weighted keyword similarity and weighted vector cosine similarity, or a combination of weighted keyword similarity and weighted reranking score during retrieval. This argument sets the threshold for similarities between the user query and chunks. If a similarity score falls below this threshold, the corresponding chunk will be excluded from the results. The default value is 0.2.
    • "keywords_similarity_weight": float This argument sets the weight of keyword similarity in the hybrid similarity score with vector cosine similarity or reranking model similarity. By adjusting this weight, you can control the influence of keyword similarity in relation to other similarity measures. The default value is 0.7.
    • "top_n": int This argument specifies the number of top chunks with similarity scores above the similarity_threshold that are fed to the LLM. The LLM will only access these 'top N' chunks. The default value is 8.
    • "variables": object[] This argument lists the variables to use in the 'System' field of Chat Configurations. Note that:
      • "knowledge" is a reserved variable, which represents the retrieved chunks.
      • All the variables in 'System' should be curly bracketed.
      • The default value is [{"key": "knowledge", "optional": true}].
    • "rerank_model": string If it is not specified, vector cosine similarity will be used; otherwise, reranking score will be used.
    • "empty_response": string If nothing is retrieved in the dataset for the user's question, this will be used as the response. To allow the LLM to improvise when nothing is found, leave this blank.
    • "opener": string The opening greeting for the user. Defaults to "Hi! I am your assistant, can I help you?".
    • "show_quote: boolean Indicates whether the source of text should be displayed. Defaults to true.
    • "prompt": string The prompt content.

Response​

Success:

{
    "code": 0,
    "data": {
        "avatar": "",
        "create_date": "Thu, 24 Oct 2024 11:18:29 GMT",
        "create_time": 1729768709023,
        "dataset_ids": [
            "527fa74891e811ef9c650242ac120006"
        ],
        "description": "A helpful Assistant",
        "do_refer": "1",
        "id": "b1f2f15691f911ef81180242ac120003",
        "language": "English",
        "llm": {
            "frequency_penalty": 0.7,
            "max_tokens": 512,
            "model_name": "qwen-plus@Tongyi-Qianwen",
            "presence_penalty": 0.4,
            "temperature": 0.1,
            "top_p": 0.3
        },
        "name": "12234",
        "prompt": {
            "empty_response": "Sorry! No relevant content was found in the knowledge base!",
            "keywords_similarity_weight": 0.3,
            "opener": "Hi! I'm your assistant, what can I do for you?",
            "prompt": "You are an intelligent assistant. Please summarize the content of the knowledge base to answer the question. Please list the data in the knowledge base and answer in detail. When all knowledge base content is irrelevant to the question, your answer must include the sentence \"The answer you are looking for is not found in the knowledge base!\" Answers need to consider chat history.\n ",
            "rerank_model": "",
            "similarity_threshold": 0.2,
            "top_n": 6,
            "variables": [
                {
                    "key": "knowledge",
                    "optional": false
                }
            ]
        },
        "prompt_type": "simple",
        "status": "1",
        "tenant_id": "69736c5e723611efb51b0242ac120007",
        "top_k": 1024,
        "update_date": "Thu, 24 Oct 2024 11:18:29 GMT",
        "update_time": 1729768709023
    }
}

Failure:

{
    "code": 102,
    "message": "Duplicated chat name in creating dataset."
}

Update chat assistant​

PUT /api/v1/chats/{chat_id}

Updates configurations for a specified chat assistant.

Request​

  • Method: PUT
  • URL: /api/v1/chats/{chat_id}
  • Headers:
    • 'content-Type: application/json'
    • 'Authorization: Bearer <YOUR_API_KEY>'
  • Body:
    • "name": string
    • "avatar": string
    • "dataset_ids": list[string]
    • "llm": object
    • "prompt": object
Request example​
curl --request PUT \
     --url http://{address}/api/v1/chats/{chat_id} \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data '
     {
          "name":"Test"
     }'

Parameters​

  • chat_id: (Path parameter)
    The ID of the chat assistant to update.
  • "name": (Body parameter), string, Required
    The revised name of the chat assistant.
  • "avatar": (Body parameter), string
    Base64 encoding of the avatar.
  • "dataset_ids": (Body parameter), list[string]
    The IDs of the associated datasets.
  • "llm": (Body parameter), object
    The LLM settings for the chat assistant to create. If it is not explicitly set, a dictionary with the following values will be generated as the default. An llm object contains the following attributes:
    • "model_name", string
      The chat model name. If not set, the user's default chat model will be used.
    • "temperature": float
      Controls the randomness of the model's predictions. A lower temperature results in more conservative responses, while a higher temperature yields more creative and diverse responses. Defaults to 0.1.
    • "top_p": float
      Also known as “nucleus sampling”, this parameter sets a threshold to select a smaller set of words to sample from. It focuses on the most likely words, cutting off the less probable ones. Defaults to 0.3
    • "presence_penalty": float
      This discourages the model from repeating the same information by penalizing words that have already appeared in the conversation. Defaults to 0.2.
    • "frequency penalty": float
      Similar to the presence penalty, this reduces the model’s tendency to repeat the same words frequently. Defaults to 0.7.
    • "max_token": integer
      The maximum length of the model's output, measured in the number of tokens (words or pieces of words). Defaults to 512. If disabled, you lift the maximum token limit, allowing the model to determine the number of tokens in its responses.
  • "prompt": (Body parameter), object
    Instructions for the LLM to follow. A prompt object contains the following attributes:
    • "similarity_threshold": float RAGFlow employs either a combination of weighted keyword similarity and weighted vector cosine similarity, or a combination of weighted keyword similarity and weighted rerank score during retrieval. This argument sets the threshold for similarities between the user query and chunks. If a similarity score falls below this threshold, the corresponding chunk will be excluded from the results. The default value is 0.2.
    • "keywords_similarity_weight": float This argument sets the weight of keyword similarity in the hybrid similarity score with vector cosine similarity or reranking model similarity. By adjusting this weight, you can control the influence of keyword similarity in relation to other similarity measures. The default value is 0.7.
    • "top_n": int This argument specifies the number of top chunks with similarity scores above the similarity_threshold that are fed to the LLM. The LLM will only access these 'top N' chunks. The default value is 8.
    • "variables": object[] This argument lists the variables to use in the 'System' field of Chat Configurations. Note that:
      • "knowledge" is a reserved variable, which represents the retrieved chunks.
      • All the variables in 'System' should be curly bracketed.
      • The default value is [{"key": "knowledge", "optional": true}]
    • "rerank_model": string If it is not specified, vector cosine similarity will be used; otherwise, reranking score will be used.
    • "empty_response": string If nothing is retrieved in the dataset for the user's question, this will be used as the response. To allow the LLM to improvise when nothing is found, leave this blank.
    • "opener": string The opening greeting for the user. Defaults to "Hi! I am your assistant, can I help you?".
    • "show_quote: boolean Indicates whether the source of text should be displayed. Defaults to true.
    • "prompt": string The prompt content.

Response​

Success:

{
    "code": 0
}

Failure:

{
    "code": 102,
    "message": "Duplicated chat name in updating dataset."
}

Delete chat assistants​

DELETE /api/v1/chats

Deletes chat assistants by ID.

Request​

  • Method: DELETE
  • URL: /api/v1/chats
  • Headers:
    • 'content-Type: application/json'
    • 'Authorization: Bearer <YOUR_API_KEY>'
  • Body:
    • "ids": list[string]
Request example​
curl --request DELETE \
     --url http://{address}/api/v1/chats \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data '
     {
          "ids": ["test_1", "test_2"]
     }'
Request parameters​
  • "ids": (Body parameter), list[string]
    The IDs of the chat assistants to delete. If it is not specified, all chat assistants in the system will be deleted.

Response​

Success:

{
    "code": 0
}

Failure:

{
    "code": 102,
    "message": "ids are required"
}

List chat assistants​

GET /api/v1/chats?page={page}&page_size={page_size}&orderby={orderby}&desc={desc}&name={chat_name}&id={chat_id}

Lists chat assistants.

Request​

  • Method: GET
  • URL: /api/v1/chats?page={page}&page_size={page_size}&orderby={orderby}&desc={desc}&name={dataset_name}&id={dataset_id}
  • Headers:
    • 'Authorization: Bearer <YOUR_API_KEY>'
Request example​
curl --request GET \
     --url http://{address}/api/v1/chats?page={page}&page_size={page_size}&orderby={orderby}&desc={desc}&name={dataset_name}&id={dataset_id} \
     --header 'Authorization: Bearer <YOUR_API_KEY>'
Request parameters​
  • page: (Filter parameter), integer
    Specifies the page on which the chat assistants will be displayed. Defaults to 1.
  • page_size: (Filter parameter), integer
    The number of chat assistants on each page. Defaults to 30.
  • orderby: (Filter parameter), string
    The attribute by which the results are sorted. Available options:
    • create_time (default)
    • update_time
  • desc: (Filter parameter), boolean
    Indicates whether the retrieved chat assistants should be sorted in descending order. Defaults to true.
  • id: (Filter parameter), string
    The ID of the chat assistant to retrieve.
  • name: (Filter parameter), string
    The name of the chat assistant to retrieve.

Response​

Success:

{
    "code": 0,
    "data": [
        {
            "avatar": "",
            "create_date": "Fri, 18 Oct 2024 06:20:06 GMT",
            "create_time": 1729232406637,
            "description": "A helpful Assistant",
            "do_refer": "1",
            "id": "04d0d8e28d1911efa3630242ac120006",
            "dataset_ids": ["527fa74891e811ef9c650242ac120006"],
            "language": "English",
            "llm": {
                "frequency_penalty": 0.7,
                "max_tokens": 512,
                "model_name": "qwen-plus@Tongyi-Qianwen",
                "presence_penalty": 0.4,
                "temperature": 0.1,
                "top_p": 0.3
            },
            "name": "13243",
            "prompt": {
                "empty_response": "Sorry! No relevant content was found in the knowledge base!",
                "keywords_similarity_weight": 0.3,
                "opener": "Hi! I'm your assistant, what can I do for you?",
                "prompt": "You are an intelligent assistant. Please summarize the content of the knowledge base to answer the question. Please list the data in the knowledge base and answer in detail. When all knowledge base content is irrelevant to the question, your answer must include the sentence \"The answer you are looking for is not found in the knowledge base!\" Answers need to consider chat history.\n",
                "rerank_model": "",
                "similarity_threshold": 0.2,
                "top_n": 6,
                "variables": [
                    {
                        "key": "knowledge",
                        "optional": false
                    }
                ]
            },
            "prompt_type": "simple",
            "status": "1",
            "tenant_id": "69736c5e723611efb51b0242ac120007",
            "top_k": 1024,
            "update_date": "Fri, 18 Oct 2024 06:20:06 GMT",
            "update_time": 1729232406638
        }
    ]
}

Failure:

{
    "code": 102,
    "message": "The chat doesn't exist"
}

SESSION MANAGEMENT​

Create session with chat assistant​

POST /api/v1/chats/{chat_id}/sessions

Creates a session with a chat assistant.

Request​

  • Method: POST
  • URL: /api/v1/chats/{chat_id}/sessions
  • Headers:
    • 'content-Type: application/json'
    • 'Authorization: Bearer <YOUR_API_KEY>'
  • Body:
    • "name": string
Request example​
curl --request POST \
     --url http://{address}/api/v1/chats/{chat_id}/sessions \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data '
     {
          "name": "new session"
     }'
Request parameters​
  • chat_id: (Path parameter)
    The ID of the associated chat assistant.
  • "name": (Body parameter), string
    The name of the chat session to create.

Response​

Success:

{
    "code": 0,
    "data": {
        "chat_id": "2ca4b22e878011ef88fe0242ac120005",
        "create_date": "Fri, 11 Oct 2024 08:46:14 GMT",
        "create_time": 1728636374571,
        "id": "4606b4ec87ad11efbc4f0242ac120006",
        "messages": [
            {
                "content": "Hi! I am your assistant，can I help you?",
                "role": "assistant"
            }
        ],
        "name": "new session",
        "update_date": "Fri, 11 Oct 2024 08:46:14 GMT",
        "update_time": 1728636374571
    }
}

Failure:

{
    "code": 102,
    "message": "Name cannot be empty."
}

Update chat assistant's session​

PUT /api/v1/chats/{chat_id}/sessions/{session_id}

Updates a session of a specified chat assistant.

Request​

  • Method: PUT
  • URL: /api/v1/chats/{chat_id}/sessions/{session_id}
  • Headers:
    • 'content-Type: application/json'
    • 'Authorization: Bearer <YOUR_API_KEY>'
  • Body:
    • "name: string
Request example​
curl --request PUT \
     --url http://{address}/api/v1/chats/{chat_id}/sessions/{session_id} \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data '
     {
          "name": "<REVISED_SESSION_NAME_HERE>"
     }'
Request Parameter​
  • chat_id: (Path parameter)
    The ID of the associated chat assistant.
  • session_id: (Path parameter)
    The ID of the session to update.
  • "name": (Body Parameter), string
    The revised name of the session.

Response​

Success:

{
    "code": 0
}

Failure:

{
    "code": 102,
    "message": "Name cannot be empty."
}

List chat assistant's sessions​

GET /api/v1/chats/{chat_id}/sessions?page={page}&page_size={page_size}&orderby={orderby}&desc={desc}&name={session_name}&id={session_id}

Lists sessions associated with a specified chat assistant.

Request​

  • Method: GET
  • URL: /api/v1/chats/{chat_id}/sessions?page={page}&page_size={page_size}&orderby={orderby}&desc={desc}&name={session_name}&id={session_id}
  • Headers:
    • 'Authorization: Bearer <YOUR_API_KEY>'
Request example​
curl --request GET \
     --url http://{address}/api/v1/chats/{chat_id}/sessions?page={page}&page_size={page_size}&orderby={orderby}&desc={desc}&name={session_name}&id={session_id} \
     --header 'Authorization: Bearer <YOUR_API_KEY>'
Request Parameters​
  • chat_id: (Path parameter)
    The ID of the associated chat assistant.
  • page: (Filter parameter), integer
    Specifies the page on which the sessions will be displayed. Defaults to 1.
  • page_size: (Filter parameter), integer
    The number of sessions on each page. Defaults to 30.
  • orderby: (Filter parameter), string
    The field by which sessions should be sorted. Available options:
    • create_time (default)
    • update_time
  • desc: (Filter parameter), boolean
    Indicates whether the retrieved sessions should be sorted in descending order. Defaults to true.
  • name: (Filter parameter) string
    The name of the chat session to retrieve.
  • id: (Filter parameter), string
    The ID of the chat session to retrieve.

Response​

Success:

{
    "code": 0,
    "data": [
        {
            "chat": "2ca4b22e878011ef88fe0242ac120005",
            "create_date": "Fri, 11 Oct 2024 08:46:43 GMT",
            "create_time": 1728636403974,
            "id": "578d541e87ad11ef96b90242ac120006",
            "messages": [
                {
                    "content": "Hi! I am your assistant，can I help you?",
                    "role": "assistant"
                }
            ],
            "name": "new session",
            "update_date": "Fri, 11 Oct 2024 08:46:43 GMT",
            "update_time": 1728636403974
        }
    ]
}

Failure:

{
    "code": 102,
    "message": "The session doesn't exist"
}

Delete chat assistant's sessions​

DELETE /api/v1/chats/{chat_id}/sessions

Deletes sessions of a chat assistant by ID.

Request​

  • Method: DELETE
  • URL: /api/v1/chats/{chat_id}/sessions
  • Headers:
    • 'content-Type: application/json'
    • 'Authorization: Bearer <YOUR_API_KEY>'
  • Body:
    • "ids": list[string]
Request example​
curl --request DELETE \
     --url http://{address}/api/v1/chats/{chat_id}/sessions \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data '
     {
          "ids": ["test_1", "test_2"]
     }'
Request Parameters​
  • chat_id: (Path parameter)
    The ID of the associated chat assistant.
  • "ids": (Body Parameter), list[string]
    The IDs of the sessions to delete. If it is not specified, all sessions associated with the specified chat assistant will be deleted.

Response​

Success:

{
    "code": 0
}

Failure:

{
    "code": 102,
    "message": "The chat doesn't own the session"
}

Converse with chat assistant​

POST /api/v1/chats/{chat_id}/completions

Asks a specified chat assistant a question to start an AI-powered conversation.

NOTE
  • In streaming mode, not all responses include a reference, as this depends on the system's judgement.
  • In streaming mode, the last message is an empty message:
    data:
    {
      "code": 0,
      "data": true
    }

Request​

  • Method: POST
  • URL: /api/v1/chats/{chat_id}/completions
  • Headers:
    • 'content-Type: application/json'
    • 'Authorization: Bearer <YOUR_API_KEY>'
  • Body:
    • "question": string
    • "stream": boolean
    • "session_id": string
Request example​
curl --request POST \
     --url http://{address}/api/v1/chats/{chat_id}/completions \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data-binary '
     {
     }'
curl --request POST \
     --url http://{address}/api/v1/chats/{chat_id}/completions \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data-binary '
     {
          "question": "Who are you",
          "stream": true,
          "session_id":"9fa7691cb85c11ef9c5f0242ac120005"
     }'
Request Parameters​
  • chat_id: (Path parameter)
    The ID of the associated chat assistant.
  • "question": (Body Parameter), string, Required
    The question to start an AI-powered conversation.
  • "stream": (Body Parameter), boolean
    Indicates whether to output responses in a streaming way:
    • true: Enable streaming (default).
    • false: Disable streaming.
  • "session_id": (Body Parameter)
    The ID of session. If it is not provided, a new session will be generated.

Response​

Success without session_id:

data:{
    "code": 0,
    "message": "",
    "data": {
        "answer": "Hi! I'm your assistant, what can I do for you?",
        "reference": {},
        "audio_binary": null,
        "id": null,
        "session_id": "b01eed84b85611efa0e90242ac120005"
    }
}
data:{
    "code": 0,
    "message": "",
    "data": true
}

Success with session_id:

data:{
    "code": 0,
    "data": {
        "answer": "I am an intelligent assistant designed to help answer questions by summarizing content from a",
        "reference": {},
        "audio_binary": null,
        "id": "a84c5dd4-97b4-4624-8c3b-974012c8000d",
        "session_id": "82b0ab2a9c1911ef9d870242ac120006"
    }
}
data:{
    "code": 0,
    "data": {
        "answer": "I am an intelligent assistant designed to help answer questions by summarizing content from a knowledge base. My responses are based on the information available in the knowledge base and",
        "reference": {},
        "audio_binary": null,
        "id": "a84c5dd4-97b4-4624-8c3b-974012c8000d",
        "session_id": "82b0ab2a9c1911ef9d870242ac120006"
    }
}
data:{
    "code": 0,
    "data": {
        "answer": "I am an intelligent assistant designed to help answer questions by summarizing content from a knowledge base. My responses are based on the information available in the knowledge base and any relevant chat history.",
        "reference": {},
        "audio_binary": null,
        "id": "a84c5dd4-97b4-4624-8c3b-974012c8000d",
        "session_id": "82b0ab2a9c1911ef9d870242ac120006"
    }
}
data:{
    "code": 0,
    "data": {
        "answer": "I am an intelligent assistant designed to help answer questions by summarizing content from a knowledge base ##0$$. My responses are based on the information available in the knowledge base and any relevant chat history.",
        "reference": {
            "total": 1,
            "chunks": [
                {
                    "id": "faf26c791128f2d5e821f822671063bd",
                    "content": "xxxxxxxx",
                    "document_id": "dd58f58e888511ef89c90242ac120006",
                    "document_name": "1.txt",
                    "dataset_id": "8e83e57a884611ef9d760242ac120006",
                    "image_id": "",
                    "similarity": 0.7,
                    "vector_similarity": 0.0,
                    "term_similarity": 1.0,
                    "positions": [
                        ""
                    ]
                }
            ],
            "doc_aggs": [
                {
                    "doc_name": "1.txt",
                    "doc_id": "dd58f58e888511ef89c90242ac120006",
                    "count": 1
                }
            ]
        },
        "prompt": "xxxxxxxxxxx",
        "id": "a84c5dd4-97b4-4624-8c3b-974012c8000d",
        "session_id": "82b0ab2a9c1911ef9d870242ac120006"
    }
}
data:{
    "code": 0,
    "data": true
}

Failure:

{
    "code": 102,
    "message": "Please input your question."
}

Create session with agent​

POST /api/v1/agents/{agent_id}/sessions

Creates a session with an agent.

Request​

  • Method: POST
  • URL: /api/v1/agents/{agent_id}/sessions
  • Headers:
    • 'content-Type: application/json'
    • 'Authorization: Bearer <YOUR_API_KEY>'
  • Body:
    • the required parameters:str
    • the optional parameters:str
Request example​

If begin component in the agent doesn't have required parameters:

curl --request POST \
     --url http://{address}/api/v1/agents/{agent_id}/sessions \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data '{
     }'

If begin component in the agent has required parameters:

curl --request POST \
     --url http://{address}/api/v1/agents/{agent_id}/sessions \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data '{
            "lang":"Japanese",
            "file":"Who are you"
     }'
Request parameters​
  • agent_id: (Path parameter)
    The ID of the associated agent.

Response​

Success:

{
    "code": 0,
    "data": {
        "agent_id": "b4a39922b76611efaa1a0242ac120006",
        "dsl": {
            "answer": [],
            "components": {
                "Answer:GreenReadersDrum": {
                    "downstream": [],
                    "obj": {
                        "component_name": "Answer",
                        "inputs": [],
                        "output": null,
                        "params": {}
                    },
                    "upstream": []
                },
                "begin": {
                    "downstream": [],
                    "obj": {
                        "component_name": "Begin",
                        "inputs": [],
                        "output": {},
                        "params": {}
                    },
                    "upstream": []
                }
            },
            "embed_id": "",
            "graph": {
                "edges": [],
                "nodes": [
                    {
                        "data": {
                            "label": "Begin",
                            "name": "begin"
                        },
                        "dragging": false,
                        "height": 44,
                        "id": "begin",
                        "position": {
                            "x": 53.25688640427177,
                            "y": 198.37155679786412
                        },
                        "positionAbsolute": {
                            "x": 53.25688640427177,
                            "y": 198.37155679786412
                        },
                        "selected": false,
                        "sourcePosition": "left",
                        "targetPosition": "right",
                        "type": "beginNode",
                        "width": 200
                    },
                    {
                        "data": {
                            "form": {},
                            "label": "Answer",
                            "name": "dialog_0"
                        },
                        "dragging": false,
                        "height": 44,
                        "id": "Answer:GreenReadersDrum",
                        "position": {
                            "x": 360.43473114516974,
                            "y": 207.29298425089348
                        },
                        "positionAbsolute": {
                            "x": 360.43473114516974,
                            "y": 207.29298425089348
                        },
                        "selected": false,
                        "sourcePosition": "right",
                        "targetPosition": "left",
                        "type": "logicNode",
                        "width": 200
                    }
                ]
            },
            "history": [],
            "messages": [],
            "path": [
                [
                    "begin"
                ],
                []
            ],
            "reference": []
        },
        "id": "2581031eb7a311efb5200242ac120005",
        "message": [
            {
                "content": "Hi! I'm your smart assistant. What can I do for you?",
                "role": "assistant"
            }
        ],
        "source": "agent",
        "user_id": "69736c5e723611efb51b0242ac120007"
    }
}

Failure:

{
    "code": 102,
    "message": "Agent not found."
}

Converse with agent​

POST /api/v1/agents/{agent_id}/completions

Asks a specified agent a question to start an AI-powered conversation.

NOTE
  • In streaming mode, not all responses include a reference, as this depends on the system's judgement.
  • In streaming mode, the last message is an empty message:
    data:
    {
      "code": 0,
      "data": true
    }

Request​

  • Method: POST
  • URL: /api/v1/agents/{agent_id}/completions
  • Headers:
    • 'content-Type: application/json'
    • 'Authorization: Bearer <YOUR_API_KEY>'
  • Body:
    • "question": string
    • "stream": boolean
    • "session_id": string
    • other parameters: string
Request example​

If the begin component doesn't have parameters, the following code will create a session.

curl --request POST \
     --url http://{address}/api/v1/agents/{agent_id}/completions \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data-binary '
     {
     }'

If the begin component have parameters, the following code will create a session.

curl --request POST \
     --url http://{address}/api/v1/agents/{agent_id}/completions \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data-binary '
     {
          "lang":"English",
          "file":"How is the weather tomorrow?"
     }'

The following code will execute the completion process

curl --request POST \
     --url http://{address}/api/v1/agents/{agent_id}/completions \
     --header 'Content-Type: application/json' \
     --header 'Authorization: Bearer <YOUR_API_KEY>' \
     --data-binary '
     {
          "question": "Hello",
          "stream": true,
          "session_id": "cb2f385cb86211efa36e0242ac120005"
     }'
Request Parameters​
  • agent_id: (Path parameter), string
    The ID of the associated agent.
  • "question": (Body Parameter), string, Required
    The question to start an AI-powered conversation.
  • "stream": (Body Parameter), boolean
    Indicates whether to output responses in a streaming way:
    • true: Enable streaming (default).
    • false: Disable streaming.
  • "session_id": (Body Parameter)
    The ID of the session. If it is not provided, a new session will be generated.
  • Other parameters: (Body Parameter)
    The parameters in the begin component.

Response​

success without session_id provided and with no parameters in the begin component:

data:{
    "code": 0,
    "message": "",
    "data": {
        "answer": "Hi! I'm your smart assistant. What can I do for you?",
        "reference": {},
        "id": "31e6091d-88d4-441b-ac65-eae1c055be7b",
        "session_id": "2987ad3eb85f11efb2a70242ac120005"
    }
}
data:{
    "code": 0,
    "message": "",
    "data": true
}

Success without session_id provided and with parameters in the begin component:

data:{
    "code": 0,
    "message": "",
    "data": {
        "session_id": "eacb36a0bdff11ef97120242ac120006",
        "answer": "",
        "reference": [],
        "param": [
            {
                "key": "lang",
                "name": "Target Language",
                "optional": false,
                "type": "line",
                "value": "English"
            },
            {
                "key": "file",
                "name": "Files",
                "optional": false,
                "type": "file",
                "value": "How is the weather tomorrow?"
            },
            {
                "key": "hhyt",
                "name": "hhty",
                "optional": true,
                "type": "line"
            }
        ]
    }
}
data:

Success with parameters in the begin component:

data:{
    "code": 0,
    "message": "",
    "data": {
        "answer": "How",
        "reference": {},
        "id": "0379ac4c-b26b-4a44-8b77-99cebf313fdf",
        "session_id": "4399c7d0b86311efac5b0242ac120005"
    }
}
data:{
    "code": 0,
    "message": "",
    "data": {
        "answer": "How is",
        "reference": {},
        "id": "0379ac4c-b26b-4a44-8b77-99cebf313fdf",
        "session_id": "4399c7d0b86311efac5b0242ac120005"
    }
}
data:{
    "code": 0,
    "message": "",
    "data": {
        "answer": "How is the",
        "reference": {},
        "id": "0379ac4c-b26b-4a44-8b77-99cebf313fdf",
        "session_id": "4399c7d0b86311efac5b0242ac120005"
    }
}
data:{
    "code": 0,
    "message": "",
    "data": {
        "answer": "How is the weather",
        "reference": {},
        "id": "0379ac4c-b26b-4a44-8b77-99cebf313fdf",
        "session_id": "4399c7d0b86311efac5b0242ac120005"
    }
}
data:{
    "code": 0,
    "message": "",
    "data": {
        "answer": "How is the weather tomorrow",
        "reference": {},
        "id": "0379ac4c-b26b-4a44-8b77-99cebf313fdf",
        "session_id": "4399c7d0b86311efac5b0242ac120005"
    }
}
data:{
    "code": 0,
    "message": "",
    "data": {
        "answer": "How is the weather tomorrow?",
        "reference": {},
        "id": "0379ac4c-b26b-4a44-8b77-99cebf313fdf",
        "session_id": "4399c7d0b86311efac5b0242ac120005"
    }
}
data:{
    "code": 0,
    "message": "",
    "data": {
        "answer": "How is the weather tomorrow?",
        "reference": {},
        "id": "0379ac4c-b26b-4a44-8b77-99cebf313fdf",
        "session_id": "4399c7d0b86311efac5b0242ac120005"
    }
}
data:{
    "code": 0,
    "message": "",
    "data": true
}

Failure:

{
    "code": 102,
    "message": "`question` is required."
}

List agent sessions​

GET /api/v1/agents/{agent_id}/sessions?page={page}&page_size={page_size}&orderby={orderby}&desc={desc}&id={session_id}

Lists sessions associated with a specified agent.

Request​

  • Method: GET
  • URL: /api/v1/agents/{agent_id}/sessions?page={page}&page_size={page_size}&orderby={orderby}&desc={desc}&id={session_id}
  • Headers:
    • 'Authorization: Bearer <YOUR_API_KEY>'
Request example​
curl --request GET \
     --url http://{address}/api/v1/agents/{agent_id}/sessions?page={page}&page_size={page_size}&orderby={orderby}&desc={desc}&id={session_id} \
     --header 'Authorization: Bearer <YOUR_API_KEY>'
Request Parameters​
  • agent_id: (Path parameter)
    The ID of the associated agent.
  • page: (Filter parameter), integer
    Specifies the page on which the sessions will be displayed. Defaults to 1.
  • page_size: (Filter parameter), integer
    The number of sessions on each page. Defaults to 30.
  • orderby: (Filter parameter), string
    The field by which sessions should be sorted. Available options:
    • create_time (default)
    • update_time
  • desc: (Filter parameter), boolean
    Indicates whether the retrieved sessions should be sorted in descending order. Defaults to true.
  • id: (Filter parameter), string
    The ID of the agent session to retrieve.

Response​

Success:

{
    "code": 0,
    "data": {
        "agent_id": "e9e2b9c2b2f911ef801d0242ac120006",
        "dsl": {
            "answer": [],
            "components": {
                "Answer:OrangeTermsBurn": {
                    "downstream": [],
                    "obj": {
                        "component_name": "Answer",
                        "params": {}
                    },
                    "upstream": []
                },
                "Generate:SocialYearsRemain": {
                    "downstream": [],
                    "obj": {
                        "component_name": "Generate",
                        "params": {
                            "cite": true,
                            "frequency_penalty": 0.7,
                            "llm_id": "gpt-4o___OpenAI-API@OpenAI-API-Compatible",
                            "max_tokens": 256,
                            "message_history_window_size": 12,
                            "parameters": [],
                            "presence_penalty": 0.4,
                            "prompt": "Please summarize the following paragraph. Pay attention to the numbers and do not make things up. The paragraph is as follows:\n{input}\nThis is what you need to summarize.",
                            "temperature": 0.1,
                            "top_p": 0.3
                        }
                    },
                    "upstream": []
                },
                "begin": {
                    "downstream": [],
                    "obj": {
                        "component_name": "Begin",
                        "params": {}
                    },
                    "upstream": []
                }
            },
            "graph": {
                "edges": [],
                "nodes": [
                    {
                        "data": {
                            "label": "Begin",
                            "name": "begin"
                        },
                        "height": 44,
                        "id": "begin",
                        "position": {
                            "x": 50,
                            "y": 200
                        },
                        "sourcePosition": "left",
                        "targetPosition": "right",
                        "type": "beginNode",
                        "width": 200
                    },
                    {
                        "data": {
                            "form": {
                                "cite": true,
                                "frequencyPenaltyEnabled": true,
                                "frequency_penalty": 0.7,
                                "llm_id": "gpt-4o___OpenAI-API@OpenAI-API-Compatible",
                                "maxTokensEnabled": true,
                                "max_tokens": 256,
                                "message_history_window_size": 12,
                                "parameters": [],
                                "presencePenaltyEnabled": true,
                                "presence_penalty": 0.4,
                                "prompt": "Please summarize the following paragraph. Pay attention to the numbers and do not make things up. The paragraph is as follows:\n{input}\nThis is what you need to summarize.",
                                "temperature": 0.1,
                                "temperatureEnabled": true,
                                "topPEnabled": true,
                                "top_p": 0.3
                            },
                            "label": "Generate",
                            "name": "Generate Answer_0"
                        },
                        "dragging": false,
                        "height": 105,
                        "id": "Generate:SocialYearsRemain",
                        "position": {
                            "x": 561.3457829707513,
                            "y": 178.7211182312641
                        },
                        "positionAbsolute": {
                            "x": 561.3457829707513,
                            "y": 178.7211182312641
                        },
                        "selected": true,
                        "sourcePosition": "right",
                        "targetPosition": "left",
                        "type": "generateNode",
                        "width": 200
                    },
                    {
                        "data": {
                            "form": {},
                            "label": "Answer",
                            "name": "Dialogue_0"
                        },
                        "height": 44,
                        "id": "Answer:OrangeTermsBurn",
                        "position": {
                            "x": 317.2368194777658,
                            "y": 218.30635555445093
                        },
                        "sourcePosition": "right",
                        "targetPosition": "left",
                        "type": "logicNode",
                        "width": 200
                    }
                ]
            },
            "history": [],
            "messages": [],
            "path": [],
            "reference": []
        },
        "id": "792dde22b2fa11ef97550242ac120006",
        "message": [
            {
                "content": "Hi! I'm your smart assistant. What can I do for you?",
                "role": "assistant"
            }
        ],
        "source": "agent",
        "user_id": ""
    }
}

Failure:

{
    "code": 102,
    "message": "You don't own the agent ccd2f856b12311ef94ca0242ac1200052."
}

AGENT MANAGEMENT​

List agents​

GET /api/v1/agents?page={page}&page_size={page_size}&orderby={orderby}&desc={desc}&name={agent_name}&id={agent_id}

Lists agents.

Request​

  • Method: GET
  • URL: /api/v1/agents?page={page}&page_size={page_size}&orderby={orderby}&desc={desc}&name={agent_name}&id={agent_id}
  • Headers:
    • 'Authorization: Bearer <YOUR_API_KEY>'
Request example​
curl --request GET \
     --url http://{address}/api/v1/agents?page={page}&page_size={page_size}&orderby={orderby}&desc={desc}&name={agent_name}&id={agent_id} \
     --header 'Authorization: Bearer <YOUR_API_KEY>'
Request parameters​
  • page: (Filter parameter), integer
    Specifies the page on which the agents will be displayed. Defaults to 1.
  • page_size: (Filter parameter), integer
    The number of agents on each page. Defaults to 30.
  • orderby: (Filter parameter), string
    The attribute by which the results are sorted. Available options:
    • create_time (default)
    • update_time
  • desc: (Filter parameter), boolean
    Indicates whether the retrieved agents should be sorted in descending order. Defaults to true.
  • id: (Filter parameter), string
    The ID of the agent to retrieve.
  • name: (Filter parameter), string
    The name of the agent to retrieve.

Response​

Success:

{
    "code": 0,
    "data": [
        {
            "avatar": null,
            "canvas_type": null,
            "create_date": "Thu, 05 Dec 2024 19:10:36 GMT",
            "create_time": 1733397036424,
            "description": null,
            "dsl": {
                "answer": [],
                "components": {
                    "begin": {
                        "downstream": [],
                        "obj": {
                            "component_name": "Begin",
                            "params": {}
                        },
                        "upstream": []
                    }
                },
                "graph": {
                    "edges": [],
                    "nodes": [
                        {
                            "data": {
                                "label": "Begin",
                                "name": "begin"
                            },
                            "height": 44,
                            "id": "begin",
                            "position": {
                                "x": 50,
                                "y": 200
                            },
                            "sourcePosition": "left",
                            "targetPosition": "right",
                            "type": "beginNode",
                            "width": 200
                        }
                    ]
                },
                "history": [],
                "messages": [],
                "path": [],
                "reference": []
            },
            "id": "8d9ca0e2b2f911ef9ca20242ac120006",
            "title": "123465",
            "update_date": "Thu, 05 Dec 2024 19:10:56 GMT",
            "update_time": 1733397056801,
            "user_id": "69736c5e723611efb51b0242ac120007"
        }
    ]
}

Failure:

{
    "code": 102,
    "message": "The agent doesn't exist."
}
